CORRUGATED BUNDLE SQUARING & STRAPPING SYSTEM

YS-305RPD+YS-LX500

The YS - 305RPD plus YS - LX500 corrugated bundle squaring & strapping system is designed to streamline packaging processes with exceptional speed and accuracy. Ideal for industries requiring reliable and efficient bundling solutions, this system ensures perfect bundle formation and secure strapping.

Key features of the YS - 305RPD include:

- High - Speed Operation: Capable of processing 18 packs per minute, it significantly boosts packaging efficiency.

- Dual Arch Strapping Machine: Equipped with dual arch technology for enhanced stability and reliability during strapping.

- 4 - Side Squaring Bundle Control: Ensures precise bundle squaring from all sides, guaranteeing neat and uniform bundles (YS - LX500 bundle turner is optional).

- Wide - Ranging Tension: With a tension range of 0 - 45 kg, it can handle various bundle weights and sizes.

- User - Friendly Design: Features an intuitive control panel for easy operation and monitoring.

- Versatile Compatibility: Compatible with PP straps of widths 5 mm, 6 mm, and thicknesses of 0.5 - 0.8 mm. It can also accommodate various strap spool sizes, with an inner diameter of 200 - 210 mm, outer diameter of 400 - 450 mm, and width of 170 - 190 mm.

- Adjustable Working Table: The working table height is set at 890 mm for optimal operator comfort.

The YS - LX500 complements the system with its efficient bundle squaring capabilities. It ensures that bundles are neatly squared and properly aligned before strapping, enhancing the overall packaging quality.

Together, the YS - 305RPD plus YS - LX500 offers a comprehensive solution for businesses looking to optimize their packaging processes. Its combination of speed, precision, and reliability makes it an ideal choice for corrugated packaging applications.
